Technical specifications

Frequency
50Hz ±5% o 60Hz ±5%
Voltage regulation
IGBT controlled (double conversion technology)
Adjusting energy parameters
Independent phase control
Selectable target voltage
380-400-415V (440-460-480V**)
Output voltage accuracy
±0,5%
Admitted load variation
Up to 100%
Admitted load imbalance [%]
100
Cooling
Forced ventilation
Ambient temperature
0/+40°C
Storage temperature
0/+60°C
Max related humidity
<95% (non condensing)
Admitted overload
150% for 1 minute (at nominal input voltage)
Colour
RAL 9005
Instrumentation
  • 10" touch panel, multilingual (on request remotely available by dedicated software connected to the same Ethernet network)
Installation
Indoor
Communication system
MODBUS TCP/IP
Overvoltage protection
  • Class I input surge arrestors
  • Class II output surge arrestors
Additional protections
  • Automatic by-pass protection

Oxygen 10-40

Type
Weight
Rated power
Max input current
Rated output current
VARIANT SHEET
200-10-40
1200
200
321
289
250-10-40
1250
250
401
361
320-10-40
1250
320
513
462
400-10-40
1400
400
642
577
500-10-40
1650
500
802
722
630-10-40
2950
630
1010
909
800-10-40
3200
800
1283
1155
1000-10-40
4000
1000
1604
1443
1250-10-40
4600
1250
2005
1804
1600-10-40
5100
1600
2566
2309
2000-10-40
5600
2000
3208
2887
2500-10-40
6100
2500
4009
3609
Type
Weight
Rated power
Max input current
Rated output current
VARIANT SHEET
200-15-50
1310
200
340
289
250-15-50
1330
250
425
361
320-15-50
1650
320
543
462
400-15-50
2700
400
679
577
500-15-50
3000
500
849
722
630-15-50
3500
630
1070
909
800-15-50
4400
800
1359
1155
1000-15-50
5100
1000
1698
1443
1250-15-50
5600
1250
2123
1804
1600-15-50
6100
1600
2717
2309
